35 kV Current Transformer

Youbian's durable 35 kV current transformer is a vertical fully enclosed structure. It consists of an expander, primary terminals, porcelain bushing, primary winding, secondary winding, and oil tank. The lower part of the product is equipped with a grounding plate for product grounding and a drain valve for taking oil samples. Come visit our factory and negotiate a customized solution together!

standard

All 35 kV current transformers comply with IEC standards and IEC 61869 recommendations. Transformers that meet specific national standards can also be provided. （IEEE C57.13，NBR6855）。

35kV High Voltage Current Transformer for Measurement, Measurement, and Protection

Rated frequency 50/60 Hz, primary current range 5-2500 A (customizable)

Fully enclosed resin casting and oil immersed, suitable for outdoor applications

Has high resistance to weather, pollution, and mechanical stress, and can be used stably for a long time

Youbian offers OEM customization: ratios, precision levels, loads, terminals, and design options

Features

5 kV current transformer

It is a vertical fully enclosed structure. It consists of an expander, primary terminals, porcelain bushing, primary winding, secondary winding, and oil tank. The lower part of the product is equipped with a grounding plate for product grounding and a drain valve for taking oil samples.

This product is suitable for the following temperatures

-45~+45 ° C; daily average temperature not exceeding+35 ° C; monthly average maximum relative humidity of 95% (at 25 ° C); The maximum wind speed shall not exceed 34m/s; Suitable for areas with seismic intensity not exceeding 8 degrees.

This outdoor dry-type current transformer is used for measurement and protection in 33kV, 35kV, 36kV, and 40.5kV power systems.

The 5 kV current transformer has been used for outdoor pole mounted and transmission lines.

The current transformer is made of high-quality UV resistant epoxy resin, with amorphous alloy iron cores for measurement and high-quality CRGO iron cores for protection. Pure electrolytic copper is used for primary and secondary applications, and both the winding and iron core are shielded.
