At Youbian, our design is centered around the 12kV rated standard of the 11 kV Vacuum Circuit Breaker, which comprehensively covers and optimizes the performance requirements of the 11 kV power grid. Unlike old technologies, these circuit breakers rely on a high vacuum environment to extinguish arcs, thereby stabilizing the power grid and ensuring personnel safety.
The "vacuum" in the 11 Kv Vacuum Circuit Breaker refers to the environment inside the vacuum arc extinguishing chamber (usually referred to as a vacuum bottle). This is the core of the system. Due to its superior dielectric strength (insulation ability) compared to air or oil, vacuum can achieve smaller contact gaps and withstand high voltages.
When our 11 Kv Vacuum Circuit Breaker is in operation, contact separation occurs inside the permanently sealed vacuum chamber. Due to the absence of gas molecules, there is almost nothing to maintain the arc, thus achieving rapid fault isolation.
Our equipment's arc extinguishing process is precise and instantaneous. Here is our design to implement its working principle:
1. Contact separation: When a fault is detected, the contacts separate.
2. Metal vapor arc: Due to the metal vapor in the contact material, an arc will briefly form.
3. Rapid diffusion: Due to the vacuum environment, metal vapor will expand and diffuse at an extremely fast speed.
4. Zero crossing circuit breaker: When the current crosses zero for the first time, the arc extinguishes due to the faster recovery rate of dielectric strength than the speed at which the voltage rises and reignites the arc.
We advocate switching to vacuum technology because it eliminates the environmental and maintenance responsibilities associated with old-fashioned oil or gas circuit breakers. The following compares why environmentally friendly circuit breakers are a better choice for modern infrastructure.
Arc extinguishing ability: medium/high vacuum (sealed) oil or compressed air
Maintenance: Very rare (lifetime sealing) high (oil replacement, cleaning contacts)
Fire risk: None (no oil and no SF6) High (oil flammable)
Service life: Long (20-30 years) Short (aging with use)
Size: Compact modular/bulky
Environmental Impact: Environmental Protection/Risk of Oil Leakage or SF6 Emissions
By adopting vacuum technology, our 11 Kv Vacuum Circuit Breaker is not only safer, but also significantly reduces operating costs throughout the entire lifecycle of the equipment.
Although these devices are deployed in the 11kV power supply network, the rated voltage of the 11kV Vacuum Circuit Breaker is 12kV to ensure necessary safety margin. The rated continuous current determines the load capacity that a circuit breaker can withstand during normal operation. We offer flexible configurations to meet specific load requirements:
Rated current 630A: suitable for standard distribution feeders and small industrial loads.
1250A to 1600A: Designed specifically for main incoming lines and heavy industrial machinery.
Customization: Higher rated values can be provided based on specific switchgear configurations.
Safe disconnection of faults is the most critical function of any vacuum circuit breaker. Our 11 Kv Vacuum Circuit Breaker has a short-circuit breaking capacity of 20kA to 31.5kA, ensuring the ability to instantly clear large fault currents without damaging downstream equipment.
We strictly adhere to global manufacturing standards. Each unit is equipped with a vacuum circuit breaker (VCB) that complies with the IEC 62271-100 standard, ensuring consistency in performance among divers.
