High Voltage Air Circuit Breaker

Explore Youbian's advanced High Voltage Air Circuit Breakers, which are designed to ensure the reliability and safety of power transmission systems. From air insulated switchgear (AIS) to gas insulated switchgear (GIS) and innovative hybrid switchgear, we offer a comprehensive product portfolio to meet various application needs. Our technology combines efficiency, sustainability, and flexibility to help utilities and various industries optimize operations while minimizing environmental impact. Learn how our cutting-edge solutions can help build resilient energy networks for the present and future.

Since its establishment, Youbian's High Voltage Air Circuit Breaker has set new industry standards, enabling you to maintain optimal performance while meeting environmental regulations. With a mature modular platform concept, our high-voltage circuit breakers can be customized according to your specific needs, ensuring effective response to extremely high voltage levels.

By choosing our High voltage air circuit breaker, you are not only investing in a product that meets your operational needs, but also supporting your commitment to sustainability and efficiency.

For decades, circuit breakers have been used to prevent surges and faults caused by circuit overload. Traditional circuit breakers use fuses, which must be replaced after each use. However, due to its enhanced features and functions, air circuit breakers have become increasingly popular in recent years.

What is an air circuit breaker?

A high voltage air circuit breaker is an important safety device for any power line. It is a switch that will automatically activate once a surge or other fault is detected. Its design purpose is to prevent system overload, which may damage devices connected to the power supply or cause fires.

The theory of circuit breakers was first proposed by Thomas Edison in 1879, but the first model to use air instead of fuses was not invented by the American electrical company Westinghouse Electric until 1949. Other models have also used oil to disconnect the current. Experts generally believe that air circuit breakers are superior to other types of circuit breakers.

Product Features

Although there are many manufacturers and models of high voltage air circuit breakers, their main features are basically the same. There are four types of air circuit breakers. But this article will mainly introduce air jet circuit breakers.

The frame of an air circuit breaker usually refers to the casing, made of aluminum, chrome steel, or other sturdy metals, used to protect internal components from dust and other environmental damage. However, it may also refer to an internal insulation frame equipped with insulation boards for accommodating and protecting contacts.

High voltage air circuit breakers typically have two pairs of contacts, but large industrial equipment may have more contacts. The first pair of contacts is usually made of copper and is used to conduct electricity along a normal path during normal operation. The second pair of contacts is made of carbon and serves as a fault protection device to prevent any damage caused by excessive current generated by the first pair of contacts.

The arc extinguishing cover of an air circuit breaker is a channel designed to limit the arc and keep its path away from other internal mechanisms. It uses insulating materials to achieve this function, as insulating materials are non-conductive and can be safely absorbed.

As the name suggests, the main operating mechanism is a component that enables the equipment to operate as expected. This component is ejected from compressed air to prevent the formation of an arc again until the voltage drops to a low level that the system can withstand without causing overload.
